Mips Technologies Malta - 2: J4 Connector; Table 7.4 J4 Pin List

7.2 Signals
MIPS® Malta™ User’s Manual, Revision 01.07 55
Copyright © 2000-2007 MIPS Technologies Inc. All rights reserved.
7.2.2 J4 Connector
The pin list for the J4 connector is shown in Table 7.4.
44 CA22 94 D5V 144 GND 194 CREV6
45 CA21 95 GND 145 D3V3 195 CREV7
46 CA20 96 GND 146 GND 196 CA15
47 CA19 97 GND 147 GND 197 CA14
48 CA18 98 D5V 148 GND 198 CA13
49 CA17 99 GND 149 D3V3 199 CA12
50 CA16 100 CUU4 150 GND 200 GA11
Table 7.4 J4 Pin List
Number Name Number Name Number Name Number Name
1 RSTN 51 GND 101 D5V 151 GND
2 PCI_AD31 52 GND 102 GND 152 NC
3 PCI_AD30 53 GND 103 D3V3 153 GND
4 PCI_AD29 54 GND 104 D3V3 154 NC
5 PCI_AD28 55 GND 105 GND 155 GND
6 GND 56 GND 106 D5V 156 NC
7 GND 57 GND 107 GND 157 GND
8 PCI_CLK 58 GND 108 D3V3 158 NC
9 GND 59 GND 109 D3V3 159 GND
10 GND 60 GND 110 GND 160 NC
11 PCI_PAR 61 GND 111 D5V 161 GND
12 PCI_FRAME
N
62 GND 112 GND 162 NC
13 PCI_IRDYN 63 GND 113 D3V3 163 GND
14 PCI_AD27 64 GND 114 D3V3 164 NC
15 PCI_AD26 65 GND 115 GND 165 GND
16 PCI_AD25 66 GND 116 D5V 166 NC
17 PCI_AD24 67 PCI_AD4 117 GND 167 GND
18 PCI_CBEN3 68 GND 118 D3V3 168 NC
19 PCI_CBEN2 69 GND 119 D3V3 169 GND
20 PCI_CBEN1 70 GND 120 GND 170 NC
21 PCI_CBEN0 71 GND 121 D5V 171 GND
Table 7.3 J3 Pin List (Continued)
Number Name Number Name Number Name Number Name
