Core Card Design
54 MIPS® Malta™ User’s Manual, Revision 01.07
Copyright © 2000-2007 MIPS Technologies Inc. All rights reserved.
7 CD30 57 GND 107 GND 157 CGPO4
8 CD29 58 GND 108 GND 158 INTN5
9 CD28 59 GND 109 D3V3 159 INTN4
10 CD27 60 D5V 110 GND 160 INTN3
11 CD26 61 GND 111 CGPI0 161 INTN2
12 CD25 62 GND 112 GND 162 INTN1
13 CD24 63 GND 113 D3V3 163 INTN0
14 CD23 64 D5V 114 CA6 164 NMIN
15 CD22 65 GND 115 GND 165 CA10
16 CD21 66 GND 116 GND 166 CA9
17 CD20 67 GND 117 CA5 167 CA8
18 CD19 68 D5V 118 GND 168 CA7
19 CD18 69 GND 119 GND 169 CGPI3
20 CD17 70 GND 120 CA4 170 D12V
21 CD16 71 GND 121 D3V3 171 D12V
22 CD15 72 D5V 122 GND 172 CGPI2
23 CD14 73 GND 123 CA3 173 CPRESN
24 CD13 74 GND 124 GND 174 APRESN
25 CD12 75 GND 125 D3V3 175 BIGEND
26 CD11 76 D5V 126 CA2 176 CGPO3
27 CD10 77 GND 127 GND 177 CGPO2
28 CD9 78 GND 128 GND 178 CGPO1
29 CD8 79 GND 129 CA24 179 CGPO0
30 CD7 80 D5V 130 GND 180 CGPI1
31 CD6 81 GND 131 CA25 181 EJTCK
32 CD5 82 D5V 132 GND 182 GND
33 CD4 83 GND 133 D3V3 183 CREV0
34 CD3 84 GND 134 GND 184 EJTMS
35 CD2 85 GND 135 GND 185 CREV1
36 CD1 86 D5V 136 GND 186 EJTDI
37 CD0 87 GND 137 D3V3 187 CREV2
38 CA23 88 GND 138 GND 188 EJTDO
39 CWRN 89 GND 139 GND 189 CREV3
40 CRDN 90 D5V 140 GND 190 EJTRSTN
41 CCSN 91 GND 141 D3V3 191 CREV4
42 CGPI6 92 GND 142 GND 192 EJDINT
43 CGPI5 93 GND 143 GND 193 CREV5
Table 7.3 J3 Pin List (Continued)
Number Name Number Name Number Name Number Name
