4-30 Mx-Series Operation Manual
Automatic Nozzle Changer (ANC)
• Functions
<Figure 4-15> shows the Automatic Nozzle Changer (ANC) which keeps spare nozzles to
automatically change nozzles for each head without shutting down the system.
<Figure 4-15 Mx-Series system ANC (Top View)>
<Figure 4-16> shows the hole numbers of 12-station module ANC and 12-station P ANC.
8-station QP ANC is equipped with nozzles for precision head.
12-station module ANC
P ANC
(
12
-
station
)
Front module ANC
(
12
-
station
)
