1-6 C-Feeder User Manual
8
56mm
○
○
○
※
15.0
-0.1
9
72mm
◆ If required, special hangers can be used. Refer to the manual or contact
CS for purchasing and mounting of special hangers.
- Applied for both paper and emboss.
- Special hanger may be used if the reel is 15mm or higher.
※ Additional reel hanger is available.
Power supply
No
Type
Power supply(Spec.)
Remark
1
C-Feeder
Power supply : DC15V, 200W
Motor authorized V : DC12V
Feeder control V: DC5V
2
Stick Feeder
Power supply: DC24V, or DC15V
There are two kinds
3
Outlet Conveyor
Power supply : DC24V
4
Reel Cutter
AC220V
Additional power connection
is required
C-FEEDER weight (Unit: kg)
Width
[mm]
8mm
12 mm
16 mm
24 mm
32 mm
44 mm
56 mm
Weight
[kg]
1.55
3.05
3.05
3.05
3.80
4.10
4.40
* The weights displayed in the table include the hanger weight.
