Mirae Mx400 - Component

4-21
PLCC 84
29.2mm x 29.2mm
●
PLCC Type IC
LCCC-16
6.4mm x 6.4mm x 2.0mm
●
LCCC-4
12.3mm x 12.3mm
●
QFP Type Ic
QFP
44(0.8mm)
13.2mm x 13.2mm x
2.5mm
●
QFP 64
17.2mm x 17.2mm x
2.5mm
●
QFP 100
14.0mm x 20.0mm x
2.71m
●
QFP 120
28.0mm x 20.0mm x
2.71m
●
QFP 160
27.2mm x 27.2mm x
2.5mm
●
QFP 208
30.6mm x 30.6mm x
3.6mm
●
Chapter 4 Regular Check 4-
Chip
Descriptio
n
Nozzles used
Component Type
Chip Code
Dimension
A
B-
1
C
D
E
P2-
1
A-
1C
H-
4C
PBGA IC
PBGA 119
14.0mm x 22.0mm x
2.3mm
●
PBGA 169
23.0mm x 23.0mm x
2.3mm
●
PBGA 208
23.0mm x 23.0mm x
2.3mm
●
PBGA 225
27.0mm x 27.0mm x
2.3mm
●
PBGA 304
31.0mm x 31.0mm x
2.3mm
●
PBGA 420
35.0mm x 35.0mm x
2.3mm
●
