6-72 Mx100/200 Series Operation Manual
already placed under the nozzle. Where no part is placed under the nozzle, this option
should not be selected because it is required to pick up part.
4. X, Y , Z , R Speed
X, Y, Z and R speeds should be set to move head for part inspection. Where part to pick
up
is heavy or does not have even surface condition, each axial speed is adjustable for
stable
part inspection (The speed for stable inspection is applicable to the speed for actual
production.)
5. Current Pocket in tray
This option applies to feeder types TFU and TSU other than 8 ~ 56mm. It is used
to inspect
parts placed in columns and rows of tray other than 1X1 pickup inspection.
Set the above items and press OK to perform part inspection.
To modify part information through Part Inspection, double click a desired item to open
the
Part Information dialog box.
