Chapter 1 Machine Setup 1-
7
No
Item Checked
Check Criteria
Measurement
Result
Time
required
Remark
Utility Check
01
1. Plant main power
(Main Distribution
Panel)
Δ, Y connection
Single phase
:R-S voltage
R-S voltage
[Volt]
S-T voltage
[Volt]
T-R voltage
[Volt]
2. Machine input
voltage
R-S voltage
[Volt]
S-T voltage
[Volt]
T-R voltage
[Volt]
 R-FG voltage
[Volt]
 S-FG voltage
[Volt]
 T-FG voltage
[Volt]
3. Air pressure
3.1 Eject Type
Gauge : 0.40
[MPa]
Reading of
gauge
attached
machine
to
3.2 Vacuum Pump Type
Air Gauge1 : 0.5
[MPa]
Air Gauge2 : 0.25
[MPa]
Front: 680-720
[mmHg]
Rear: 680-720
[mmHg]
4.Temperature/humidity
18 - 28
[ ]℃
RH 40-60
RH [%]
02
Line Layout (Sketch)
1. Machine location
Floor, location
