Mirae Mx400 - Page 302

Mx-Series Manual
Conveyor
Linear Motor Stator (before
running)
Check foreign materials
betweenstator magnets.
24 Hours
4-4
Machine interior check
(before running)
Check foreign materials at
the driving unit.
24 Hours
4-5
Abnormal noise check (after
running)
Check abnormal
noise/vibration.
24 Hours
4-6
Timing Belt and Pulley
check
Check wear of timing belt
and pulley.
500 Hours
4-31
Casting Off NG Part
Periodic cleaning
500 Hours
4-35
Lead Screw/Linear Slide
Periodic cleaning and
greasing
1500 Hours
4-36
Timing Belt
Check wear and damage.
1500
Hours
4-41
Timing Belt Tension Check
Adjust to a moderate tension.
1500 Hours
4-42
Board Transfer Belt (Ring
Belt)
Check wear and damage of
the ring belt.
3000
Hours
4-44
Vision
Camera lens and lens cover
Clean and check the camera
lens.
150 Hours
4-7
ANC
ANC
Check the sensor
attachment.
1500 Hours
4-38
Head
Nozzle Check
Prevent introduction of
foreign materials.
150 Hours
4-9
Z-axis Nozzle Shaft Moving
Check
Check wear of spline and
bending of shaft.
500 Hours
4-25
Z-axis Rack & Pinion check
Check greasing and interval.
500 Hours
4-27
R-axis Bearing check
Check wear of bearing and
bush.
500 Hours
4-29
Z-axis Linear Slide
Periodic cleaning and
greasing
500 Hours
4-32
Cover
Air pressure check (before
running)
1. Main Air
2. Head blow pressure
3. Head suction
pressure
24 Hours
4-3
Fan-filter check
Check cleanness of the fan-
filter.
150 Hours
-
Air Filter Check
Drain value open
500 Hours
4-33
3-4
Regular Checklist for Greasing
