MELF
Dia: 2.4mm Length:
5.0mm
●
Transistors
SOT 23
3.0mm x 2.6mm x
1.1mm
●
SOT 89
4.5mm x 4.3mm x
1.6mm
●
SOT 143
3.0mm x 2.6mm x
1.1mm
●
SOT 223
6.7mm x 7.3mm x
1.6mm
●
Chip Description
Nozzles used
Chip Type
Chip Code
Dimension
A
B-
1
C
D
E
P2-
1
A-
1C
H-
4C
Transistors
SOT 323
2.2mm x 2.2mm x
1.0mm
●
SOT 343
2.0mm x 2.1mm x
1.0mm
●
MW-4
3.0mm x 2.6mm x
1.1mm
●
MW-7
6.7mm x 7.3mm x
1.8mm
●
Power Transistors
D-Pak
10.0mm x 6.6mm x
2.7mm
●
SO Type IC
SO 6
3.8mm x 6.0mm x
1.5mm
●
SO 8
4.9mm x 6.0mm x
1.6mm
●
SO 14
8.7mm x 6.0mm x
1.6mm
●
SO 16
10.0mm x 6.0mm x
1.6mm
●
SO 14L
9.1mm x 10.3mm x
2.5mm
●
