4- 36 Mx-Series Manual
Air is supplied to the machine through the Drain Catch Filter and Air
Filter.
Each part is equipped with a filter to catch moisture and dirt.
If the filter fails to function normally, contaminated air could be
supplied, resulting in critical damage to the machine’s performance
and a shortened lifetime.
Therefore, the filters must be checked regularly.
Drain Catch Filter Check Procedure
The drain collected in the filter case is automatically drained
through the drain valve. Since the filter element may be blocked by
foreign materials or its pressure may increase greatly during use, it
should be checked every 1 or 2 years and cleaned or replaced if
necessary.
Check Procedure
1. Unplug the machine.
The filter replacement
period is subject to
change, depending on
the conditions of the
air used.
To Next Page
