4- 46 Mx-Series Manual
Board Transfer Belt(Ring Belt) check
Module: Conveyor
The ring belt is a part that is subject to wear and damage when used for a long time and a
damaged one should be replaced (Lifetime: 8,760 Hours).
Outlet Belt Center (Work) belt
Inlet Belt
Unplug the machine according to the normal procedure.
Visually inspect the 6 belts on the front (inlet /center /outlet) and rear (inlet /center /outlet)
sides, while rotating them.
Replace a damaged belt with a new one.
To Next Page
