Chapter 1. Machine Setup 1-
7
4. Using a wrench, fix the bolts into the holes below.
5. Connect one side of the cable to the TFU panel at the rear of the mounter and the other
side to the connector at the left of the Tray Feeder.
Bolt Holes
