A. Packing List
1) Tray Feeder - 1Set
2) Pallet - 20 EA
3) Cable (1 Set) - Power 1EA, CAN Communication 1EA
B. BOM Tree
(MODULE) (SUB1) (SUB2) (DETAIL)
2100F-30000-300
TF5
MAIN FRAME ASSY
2100F-31000-200
Y AXIS ASSY
2100F-32000-200
Y AXIS BASE FRAME
2100F-32100-000
Y IDLE PULLEY ASSY
2100F-32200-000
Y DRIVEN PULLEY ASSY
2100F-32300-000
Y TENSION PULLEY ASSY 1
2100F-32400-000
Y TENSION PULLEY ASSY 2
2100F-3240A-000
Y MOTOR ASSY
2100F-32600-200
PALLET FIXED PIN ASSY 1
2100F-32600-000
PALLET FIXED PIN ASSY 2
2100F-3260A-000
VACUUM PAD ASSY
2100F-32700-000
VACUUM PAD SETTING
ASSY
2100F-32800-000
MAGAZINE TOP ASSY
PALLET ASSY
2422H-15700-100
Z AXIS ASSY
2100F-33000-000
COVER ASSY
2100F-34000-000
