MIRCOM TECHNOLOGIES LIMITED, ADC Series: Autodialer Telephone Access Systems Page 29
Press # to store or * to abort entry. After pressing the store button, the next display should appear...
-Program Options-
Press *
To exit
Please enter choice:
Press * to exit to PROGRAM MODE menu. To quit, enter *000 while at PROGRAM MODE menu to return to
NORMAL MODE.
NOTE: To restore Master Code, please see FIG. 12 for location of reset pads.
SELECT “DOOR OPEN CODE” FOR MAIN AND AUXILIARY DOORS (DTMF only)
This feature will allow the user to change the Door Open Code (DTMF only) to any desired digit from 0 to 9. This
feature is particularly useful when the default door open code for opening the Main or Auxiliary doors is false-
triggering the door strike “open” due to a “series of tones” produced by some older answering machines when it
answers a call. It is recommended to select a stable Door Open Code to improve security. These “Door Open Codes”
are used by all Residents to release the door by simply dialling the assigned digit on their telephone while on-line
with their visitors.
NOTE: The Door Open Code for pulse (rotary) type telephones is a fixed digit “9". Dialling a pulse digit “9" will
activate the main door relay. An auxiliary door relay can be activated only by a standard DTMF Code as
programmed; there is no provision for pulse activation.
To change the Door Open Code for the Main Door:
Scroll though until you reach the feature as shown below.
[1=Bck] [3=Fwd]
Do you want to edit
DTMF Code#1?
[*=Abort] [#=Yes]
Press # to access the feature. The next display screen should appear...
-Program Options-
Enter DTMF digit
to open door ( _ ) Digit “9" is the factory default.
Please enter choice:
Enter a number from 0 to 9 for code to open the main door. The next display screen should appear...
-Program Options-
#=Store, *=Abort
to open door ( x )
Please enter choice:
Press # to store or * to abort entry.
To quit, enter *000 while at the PROGRAM MODE menu to return to NORMAL MODE.
