Mircom flexnet User Manual

FleX-Net
TM
Installation and Operation Manual
9
Display Modules
Model Description
DM-1008A Eight Initiating Circuit Module
SGM-1004A Four NAC circuit Module
RM-1008A Eight Relay Circuit Module
PR-300 Polarity Reversal and City Tie Module
UDACT-300A Digital Communicator/Dialer Module
Model Description
FDX-008 Fan Damper Module
DSPL-420
4 line by 20 charactor display which can be
mounted into backboxes BBX-1072A(RA),
BBX-1072ADS(ARDS), BB-5008(R), BB-5014
and the BBX-FXMNS Backbox.
DSPL-2440
Graphic display which can be mounted in
backboxes BBX-1072A(RA),
BBX-1072ADS(ARDS), BB-5008(R), BB-5014
and the BBX-FXMNS Backbox
POLARITY
REVERSAL
ALARM
POLARITY
REVERSAL
SUPV
CITY
TIE
+ | - + | - + | -
JW4
P1 P2
OFF AUTO ON TROUBLE
OFF AUTO ON TROUBLE
OFF AUTO ON TROUBLE
OFF AUTO ON TROUBLE
OFF AUTO ON TROUBLE
OFF AUTO ON TROUBLE
OFF AUTO ON TROUBLE
OFF AUTO ON TROUBLE OFF AUTO ON TROUBLE
Flexnet
System Normal
Flexnet
System Normal
