System Components
10
Audio and Telephone Modules
Model Description
IPS-2424/DS
Programmable Input Switches Module (mounts
with the FX-2009-12N and can also be part of
the RAXN-LCD)
RAM-1032
RAM-1032TZ
RAM-1032TZDS
Model RAM-1032 Main Chassis Remote
Annunciator with 32 Bi-coloured LEDs. Model
RAM-1032TZ/DS Main Chassis Remote
Annunciator with 16 Bi-coloured LEDs and 32
trouble LEDs.
RAX-1048TZ
RAX-1048TZDS
Model RAX-1048TZ/DS Adder Annunciator
Chassis with 48 Bi-coloured LEDs and 48
trouble LEDs.
Model Description
QMP-5101N Network Master Paging Control Panel
QMP-5101NV
Network Master Paging Control Panel (Vertical
Mount) mounts within the BBX-FXMNS
enclosure.
QMT-5302N Network Master Telephone Control Panel
