FleX-Net
TM
Installation and Operation Manual
17
Figure 4: BBX-1072ADS Flush and Surface Installation and Dimensions
Material:
Cold rolled steel
16GA (0.059”) thic
k for backbox
14GA (0.075”) thick for door
Finish:
Painted except for hinges
20
22
