Mechanical Installation and Dimensions
18
Figure 5: BB-5008 Enclosure Installation Instructions and Dimensions
Note:
Leave botto
m of box conduit free for b
atteries. Mount
the power supply in the sam
e manner as shown
in
Figure 7
.
Backbox
BB-5008 Backbox
DOX-5008M Metal Door
Backbox with DOX-5008M Door
Material:
Cold rolled steel
16GA (0.059”) thic
k for backbox
14GA (0.075”) thic
k for door
Finish:
Painted except for hinges
21
23
