3.2 FX-401 System Components

The following table describes the components of the FX-401.

Table 1 FX-401 System Components

Model Description

FX-401

Model FX-401, black backbox, red door enclosure

comes complete with main board, power supply,

transformer and main display.

MAM-3500 Main Display

DOX-1024DS White enclosure door

DOX-1024DSR Red enclosure door

ALC-480 480 Point Dual Loop Adder

Visual

Indicator Test

Table of Contents3
