12.0 Appendix E - Battery Calculations
CONTINUED ON NEXT PAGE ...
IMPORTANT NOTICE
The main AC branch circuit connection for Fire Alarm Control Unit must provide a dedicated continuous power without provision of any
disconnect devices. Use #12 AWG wire with 600-volt insulation and proper over-current circuit protection that complies with the local
codes. For specifications see Appendix D - Specifications And Features.
Power Requirements (All currents are in amperes)
Model Number Description Qty Standby
Total
Standby
Alarm
Total
Alarm
FX-401 FX-401 FACP with Dialer X 0.390 = 0.630 =
ALC-480 480 Point Dual Loop Adder X 0.120 = 0.200 =
RAM-3500-LCD
Remote Annunciator with 4-
line LCD Display
X 0.070 = 0.100 =
RAX-LCD-LITE
Remote Annunciator with 4-
line LCD Display
X 0.065 = 0.080 =
PR-300
Polarity Reversal and City
Tie Module
X 0.050 = 0.300 =
SRM-312W/312R Smart Relay Module X 0.030 = 0.030 per relay LED =
RAM-1032TZDS
32 Point Remote
Annunciator
X 0.050 = 0.300 =
RAX-1048TZDS
48 Point adder annunciator
display
X 0.022 =
1 zone active: 0.026
2 zone active: 0.030
3 zone active: 0.035
4 zone active: 0.039
48 zone active: 0.262
=
RTI-1
Remote Trouble Indicator,
Buzzer and LED
X .035 = .035 =
MIX-4040 Dual Input Module X .0011 = .0032 =
MIX-4041 Mini Dual Input Module X .0011 = .0032 =
MIX-4042 Conventional Zone Module X .000750 = .00235 =
MIX-4045 Dual Relay Module X .0011 = .00235 =
MIX-4046 Supervised Output Module X .0011 = .00235 =
MIX-4070 Short Circuit Isolator Module X .000575 = .018 =
MIX-4010
Photoelectric Smoke
Detector
X .000160 = .0032 =
MIX-4010-ISO
Photoelectric Smoke
Detector with Isolator
X .000160 = .0032 =
MIX-4020 Multi-Sensor Detector X .000160 = .0032 =
MIX-4020-ISO
Multi-Sensor Detector with
Isolator
X .000160 = .0032 =
MIX-4030 Tri-Mode Heat Detector X .000160 = .0032 =
MIX-4030-ISO
Tri-Mode Heat Detector with
Isolator
X .000160 = .0032 =
INX-10A Main Chassis (10 Amp) X 0.035 = 0.0150 =
Device & Remote LEDs (Maximum 20 per loop) X =
Signal Load (bells, horns, strobes, and etc.) X =
Auxiliary Power Supply (Aux 1, Aux 2, Un-filtered) =
Alarm
=
Total currents (Add above currents) STANDBY (A)(B)
