Mitel 3000
Broadband Module Manual
7
CONNECTING A PC TO THE LA
N
A
DSL
Port
1
Port 2
Port
3
Port
4
Power up the PC.
Connect the Ethernet port on the PC
to any LAN port (1 - 4) on the MDF
using a Cat 5 cable / patch cord.
Check that the light on the MDF cover for the port
the PC is connected to is lit solid. This indica
tes a
good Ethernet connection
between the PC and
the Broadband Module.
9
11
