Mitel 3000 User Manual

Mitel 3000
Broadband Module Manual
16
CONNECTING TO AN EXTERNAL DSL OR CABLE MODEM
The Internet access can be provided through an external DSL or Cable Modem. Typically the
connection to an external modem is via an IP Gateway. The IP gateway is provided via the
WAN port on the Broadband module.
Connecting the External Modem / Data Network
Connect a 10/100 Base T connection from the external modem / data network to the WAN
connection on the Broadband Module as shown.
Programming the Broadband Module for connection to an External Modem
Connect to the Broadband Module programming Interface as described on page
8.
