Mitel 3000
Broadband Module Manual
5
E
XA
MPLE
S
The on-board ADSL modem is used to conne
ct directly to an ADSL line.
The ETH/DMZ port is used to conne
ct to an external SDSL or Cable modem.
The ETH/DMZ port is used to conne
ct to a Gateway into a private network.
Private
Network
Internet
Internet
