4G9 ENGINE (E-W) -
Specifications
11A-1-6a
Items Nm
Exhaust manifold (M8) 17
Injector and fuel pump assembly (GDI)
Fuel low pressure pipe (M6) 18
Fuel low pressure pipe (M8) 9
Fuel nipple 9
Clamp 9
Fuel feed pipe 11
Fuel pump 17
Harness bracket 11
Fuel return pipe 11
Fuel return pipe clamp 9
Fuel high pressure regulator 18
Fuel pressure sensor <For CARISMA> 23
Fuel pressure sensor <For PAJERO io> 18
Spacer 18
Pump camshaft case 23
Injector holder 22
Delivery pipe and injector 11
Water pump and water hose
Water pump 24
Water inlet pipe 14
Thermostat case 24
Water inlet fitting <Except DOHC- GDI for PAJERO io> 19
Water inlet fitting <DOHC- GDI for PAJERO io> 23
Water by-pass fitting 23
Water pipe 13
Water outlet fitting <Except DOHC- GDI for PAJERO io> 14
Water outlet fitting <DOHC-GDI for PAJERO io> 23
Engine coolant temperature gauge unit 10
Engine coolant temperature sensor 29
Water fitting 23
Rocker arms and camshaft
Lock nut 9
Rocker arm shaft 31
Rocker cover 3.5
Bearing cap bolt (M6) 11
Bearing cap bolt (M8) 24
Beam camshaft cap (M8) 21
PWEE9502-E
E
Dec. 1998Mitsubishi Motors Corporation Revised
