4G9 ENGINE (E-W) -
Specifications
11A-1-6b
Items Nm
Beam camshaft cap (M6) 11
Rocker cover and camshafts (MIVEC)
Rocker cover 4
Oil pump 11
Arm spring holder 11
Camshaft bearing cap (M6) 11
Camshaft bearing cap (M8) 23
Oil control valve 9
Rocker arms and rocker shaft caps (MIVEC)
Rocker shaft cap 11
Cylinder head and valves
CylInder head bolt 74 Nm an d then completely loosen,
finally tighten 20 Nm + 90_ +90_
Oil pressure switch 10
Front case and oil pump
Oil pump cover 10
Oil pump case 14
Relief plug 44
Oil screen 19
Oil pan 7
Upper oil pan <Only M6 ´ 121> 7
Upper oil pan <Except M6 ´ 121> 11
Upper oil pan <M8> 24
Lower oil pan 7
Cover 7
Baffle plate <For CARISMA, SPACE STAR only> 7
Drain plug 39
Oil pressure switch 10
Baffle plate mounting bolt 7
Piston and connecting rod
Connecting rod cap nut 20 + 90_ to 100_
Crankshaft, cylinder block, flywheel and drive plate
Bearing cap bolt 25 + 90_ to 100_
Oil seal case 11
Bell housing cover 9
Rear plate 11
Drive plate bolt 98
Flywheel bolt 98
Baffle plate 9
Knock sensor 22
PWEE9502-E
E
Dec. 1998Mitsubishi Motors Corporation Revised
