Mitsubishi 4G9 series

4G9 ENGINE (E-W) -
Water Pump and Water Hose
11A-7-5
"
F
A
ENGINE COOLANT TEMPERATURE GAUGE UNIT
INSTALLATION
(1) Apply th e specified sealant to t h e threads.
Specified sealant:
3M ATD Part No.8660 or equivalent
"
G
A
ENGINE COOLANT TEMPERATURE SENSOR
INSTALLATION
(1) When reusing the sensor, apply the specified sealant
to the threads.
Specified sealant:
3M Nut Locking Part No.4171 or equivalent
"
H
A
WATER BY-PASS FITTING INSTALLATION
(1) Apply 3 mm diameter of Form-In-Place Gasket (FIPG)
to the location shown in the illustration.
Specified sealant:
Mitsubishi Genuine Part No.MD970389 or
equivalent.
"
I
A
WATER FITTING INSTALLATION
(1) Apply 3 mm diameter of Form-In-Place Gasket (FIPG)
to the location shown in the illustration.
Specified sealant:
Mitsubishi Genuine Part No.MD970389 or
equivalent.
<DOHC-GDI for PAJERO io>
PWEE9502-E
E
Dec. 1998Mitsubishi Motors Corporation Added
