4G9 ENGINE (E-W) -
Rocker Cover and Camshafts (MIVEC)
11A-8a-5
PWEE9502-A
E
Nov. 1995Mitsubishi Motors Corporation
Added
"
G
A
ROCKER COVER INSTALLATION
Apply the specified sealant to th e area shown.
Specified sealant:
3M ATD part No. 8660 or equivalent
VALVE CLEARANCE ADJUSTMENT
Adjustment must be performed with th e cylinder at the to p
dead center on the compression stroke.
(1) Inserting the special tool between one of two adjusting
screws and the valve and adjust t h e clearance.
(2) Then adjust the other adjusting screw in the same way.
ROCKER ARM PISTON INSPECTION
(1) Screw in th e special tool to the rocker arm piston for
high speed side rocker arm and check that the piston
can be lifted up lightly by hand.
MB991477
MB991478
MB991477
MB991478
MB991479
To Next Page
