Mitsubishi 4G9 series

4G9 ENGINE (E-W) -
Rocker Cover and Camshafts (MIVEC)
11A-8a-4
PWEE9502-A
E
Nov. 1995Mitsubishi Motors Corporation Added
(2) Apply the specified sealant to t he front and rear camshaft
bearing caps at the positions shown. Position th e
camshaft bearing caps and tighten their mounting bolts
not numbered in the illustration. Then tighten the
remaining (numbered) bolts in the order shown in the
illustration to install the bearing caps an d camshaft holder
to the cylinder head.
Specified sealant:
3M ATD part No. 8660 or equivalent
"
E
A
OIL CONTROL VALVE INSTALLATION
(1) Apply th e specified sealant to t h e area shown.
Specified sealant:
3M ATD Part No. 8660 or equivalent
"
F
A
OIL SEAL INSTALLATION
13713
14
11
10842612
95
Sealant
Sealant
Sealant
Sealant
MD998713
