Mitsubishi FX3U Series Programming Manual

35
FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
2 Overview (Sequence Program)
2.6 Program Memory and Devices
1
Introduction
2
Overview
3
Instruction List
4
Devices in Detail
5
Specified the Device & Constant
6
Before Programming
7
Basic Instruction
8
FNC00-FNC09 Program Flow
9
FNC10-FNC19 Move & Compare
10
FNC20-FNC29 Arith. & Logic Operation
2. In FX3G/FX3GC PLCs
FX3G/FX3GC PLCs are equipped with the EEPROM memory as standard.
1) When using the built-in memory (without attached memory cassette)
2) When using an attached memory cassette
*1
(without using the built-in program memory)
CPU System ROM
Built-in program memory
(EEPROM)
Parameter
File register (D)
Special setting
Comment
Sequence program
(EEPROM)
Memory cassette
Built-in device memory (RAM, EEPROM)
[Bit device memory]
• Data register (D)
• Timer present value register (T)
• Counter present value register (C)
• Index register (V, Z)
Contact image memory
• Input relay (X) • Output relay (Y)
• Auxiliary relay (M) • State relay (S)
Timer contact and time counting coil
Counter contact, counting coil, and reset coil
• Extension register (R)
[Data memory]
Transfer and initialization by
instructions
Extension file register (ER)
Not attached
CPU System ROM
Built-in program memory
(EEPROM)
Not used
(EEPROM)
Parameter
File register (D)
Special setting
Comment
Sequence program
Extension file register (ER)
Built-in device memory (RAM, EEPROM)
[Bit device memory] [Data memory]
Transfer and initialization by
instructions
Contact image memory
· Input relay (X) · Output relay (Y)
· Auxiliary relay (M) · State relay (S)
Timer contact and time counting coil
Counter contact, counting coil, and reset coil
· Data register (D)
· Timer present value register (T)
· Counter present value register (C)
· Index register (V, Z)
· Extension register (R)
Memory cassette
The PLC automatically recognizes attachment of a
memory cassette (when the power is turned ON),
and disconnects the built-on program memory.
(The priority is given to the memory cassette.)
*1. A memory cassette can be connected only to FX
3G PLC.

Mitsubishi FX3U Series Specifications

General

Model	FX3U Series
Program Memory	64k steps
Execution Speed	0.065 μs/basic instruction
Type	PLC (Programmable Logic Controller)
Power Supply	100-240V AC
I/O Points	Up to 384
Communication	USB
Expansion	Supported via expansion modules
High-Speed Counters	Up to 6 channels
Analog Input/Output	Available via expansion modules
Temperature Range	0 to 55°C
Programming Language	Ladder Logic, Structured Text
Built-in Functions	PID control
Humidity	5 to 95% (non-condensing)
