743
FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
34 FX3U-CF-ADP Applied Instructions – FNC300 to FNC305
34.5 FNC 304 – FLCMD / FX3U-CF-ADP command
31
FNC276-FNC279
Data
Transfer 3
32
FNC280-FNC289
High-Speed
Processing 2
33
FNC290-FNC299
Extension File
Register
34
FNC300-FNC305
FX
3U
-CF-ADP
35
SFC•STL
Programming
36
Interrupt
Function
37
Special Device
38
Error Code
A
Version Up
Information
B
Execution Times
34.5.1 Detailed explanation of setting data
Details on the setting data in the FLCMD instruction are as shown below.
*1. The CompactFlash
TM
card is available in the "mounted" status.
*2. The CompactFlash
TM
card is unavailable in the "unmounted" status.
Cautions
It is not permitted to use an "RS (FNC 80)/RS2 (FNC 87)"/"IVCK (FNC270) to IVMC (FNC275)" instruction and an
"FLCRT (FNC300) to FLSTRD (FNC305)" instruction for the same port.
Setting items Description Data Type
Contents of instruction for operation
K0 to K63 : Forcibly writes the buffered data of the specified file ID to the CompactFlash
TM
card.
K-1 : Forcibly writes all buffered data to the CompactFlash
TM
card.
K256(H100) : Sets the CompactFlash
TM
card to the mounted status
*1
.
K512(H200) : Sets the CompactFlash
TM
card to the unmounted status
*2
.
K1280(H500) : Clears error codes stored in the CF-ADP.
16-bit binary
n
Channel number used by the CF-ADP
K1 : ch1
K2 : ch2
16-bit binary
S
