B Instruction Execution Time
B-5 Execution Time of Pulse Generation Instruction P in Each Applied Instruction
Appendix B-5 Execution Time of Pulse Generation Instruction P in Each Applied
Instruction
•FX3U/FX3UC PLCs
•FX3G/FX3GC PLCs (Standard mode)
Applied instruction Execution time Remarks
MOV instruction (FNC 12)
Execution time at rising edge of input: Execution time in ON status 1.22 µs in MOVP instruction
Non-execution time: Execution time in OFF status
Other applied instructions
Execution time at rising edge of input: Execution time in ON status + 0.45
µs
Non-execution time: Execution time in OFF status + 0.45 µs
Applied instruction Execution time Remarks
MOV instruction (FNC 12)
Execution time at rising edge of input: Execution time in ON status = 4.98 µs
Non-execution time: Execution time in OFF status = 0.8 µs
BCD instruction (FNC 18)
Execution time at rising edge of input: Execution time in ON status = 5.03 µs
Non-execution time: Execution time in OFF status = 0.75 µs
BIN instruction (FNC 19)
Execution time at rising edge of input: Execution time in ON status = 5.03 µs
Non-execution time: Execution time in OFF status = 0.75 µs
ADD instruction (FNC 20)
Execution time at rising edge of input: Execution time in ON status = 6.37 µs
Non-execution time: Execution time in OFF status = 0.75 µs
SUB instruction (FNC 21)
Execution time at rising edge of input: Execution time in ON status = 6.47 µs
Non-execution time: Execution time in OFF status = 0.75 µs
MUL instruction (FNC 22)
Execution time at rising edge of input: Execution time in ON status = 7.07 µs
Non-execution time: Execution time in OFF status = 0.75 µs
DIV instruction (FNC 23)
Execution time at rising edge of input: Execution time in ON status = 7.03 µs
Non-execution time: Execution time in OFF status = 0.75 µs
INC instruction (FNC 24)
Execution time at rising edge of input: Execution time in ON status = 3.48 µs
Non-execution time: Execution time in OFF status = 0.75 µs
DEC instruction (FNC 25)
Execution time at rising edge of input: Execution time in ON status = 3.48 µs
Non-execution time: Execution time in OFF status = 0.75 µs
WAND instruction (FNC 26)
Execution time at rising edge of input: Execution time in ON status = 6.42 µs
Non-execution time: Execution time in OFF status = 0.75 µs
WOR instruction (FNC 27)
Execution time at rising edge of input: Execution time in ON status = 6.42 µs
Non-execution time: Execution time in OFF status = 0.75 µs
WXOR instruction (FNC 28)
Execution time at rising edge of input: Execution time in ON status = 6.42 µs
Non-execution time: Execution time in OFF status = 0.75 µs
Other applied instructions
Execution time at rising edge of input: Execution time in ON status + 0.45 µ
s
Non-execution time: Execution time in OFF status + 0.45 µs
