20 Positioning Control – FNC150 to FNC159
20.3 FNC152 – TBL / Batch Data Positioning Mode
11
FNC30-FNC39 Rotation and Shift
12
FNC40-FNC49 Data Operation
13
FNC50-FNC59 High-Speed Processing
14
FMC60-FNC69 Handy Instruction
15
FNC70-FNC79 External FX I/O Device
16
FNC80-FNC89 External FX Device
17
FNC100-FNC109 Data Transfer 2
18
FNC110-FNC139 Floating Point
19
FNC140-FNC149 Data Operation 2
20
FNC150-FNC159 Positioning Control
20.3 FNC152 – TBL / Batch Data Positioning Mode
Outline
This instruction executes one specified table operation from the data table set in GX Developer (Ver. 8.24A or later).
→ For explanation of the instruction, refer to the Positioning Control Edition manual.
→ For cautions on using special high-speed output adapters,
refer to the Positioning Control Edition manual.
*1. This function is supported only in FX
3U/FX3UC PLCs.
1. Instruction format
2. Set data
3. Applicable devices
S1 : Specify Y000, Y001 or Y002
*1
transistor output from the main unit, or specify Y000, Y001, Y002
*3
or Y003
*3
from a high-speed output special adapter
*2
.
*1. Y002 is not available in FX3G PLC (14-point and 24-point type) and FX3GC PLC.
*2. High-speed output special adapters can be connected only to FX3U PLC.
*3. To use Y002 and Y003 with a high-speed output special adapter, connected a second high-speed output
special adapter.
Points
• When using a relay output type or triac output type FX3U PLC, a special high-speed output adapter is
required.
• Outputs of special high-speed output adapters work as differential line drivers.
Explanation of function and operation
Caution on writing during RUN
Writing is disabled to a circuit block including the TBL (FNC152) instruction during RUN.
Instruction Description
DVIT (FNC151)
*1
Interrupt positioning
PLSV (FNC157) Variable speed pulse output
DRVI (FNC158) Drive to increment
DRVA (FNC159) Drive to absolute
Operand type Description Data type
Device number (Y) from which pulses are to be output Bit
n Table entry number [1 to 100] to be executed 32-bit binary
Oper-
and
Type
Bit Devices Word Devices Others
System User Digit Specification System User
Special
Unit
Index
Con-
stant
Real
Number
Charac-
ter String
Pointer
XYMTCSD.b KnX KnY KnM KnS T C D R U\G VZModifyKH E ""P
S
1
n 33
DTBL
32-bit Instruction
17 steps
Mnemonic Operation Condition
Continuous
Operation
−
16-bit Instruction
Mnemonic Operation Condition
FNC 152
TBL
D
D
D
Command
input
FNC152
DTBL
D n
