B Instruction Execution Time
B-2 Step Ladder Instruction Execution Time
31
FNC276-FNC279 Data Transfer 3
32
FNC280-FNC289 High-Speed Processing 2
33
FNC290-FNC299 Extension File Register
34
FNC300-FNC305 FX
3U
-CF-ADP
35
SFC•STL Programming
36
Interrupt Function
37
Special Device
38
Error Code
A
Version Up Information
B
Execution Times
Appendix B-2 Step Ladder Instruction Execution Time
•FX3U/FX3UC PLCs
•FX3G/FX3GC PLCs
Appendix B-3 Label (P/I) Execution Time
•FX3U/FX3UC PLCs
•FX3G/FX3GC PLCs
Instruction
Execution time in ON status (µs) Execution time in OFF status (µs)
Remarks
16-bit instruction 32-bit instruction 16-bit instruction 32-bit instruction
STL 5.1 + 1.6n ⎯
n: Number of recombination
n = 0: When there is no
recombination
RET 2.9 ⎯
Instruc-
tion
Standard mode Extension mode
Remarks
Execution time in ON
status (µs)
Execution time in OFF
status (µs)
Execution time in ON
status (µs)
Execution time in OFF
status (µs)
16-bit
instruc-
tion
32-bit
instruc-
tion
16-bit
instruc-
tion
32-bit
instruc-
tion
16-bit
instruc-
tion
32-bit
instruc-
tion
16-bit
instruc-
tion
32-bit
instruc-
tion
STL 1.8 + 0.49n ⎯ 2.18 + 0.49n ⎯
n: Number of recombination
n = 0: When there is no
recombination
RET 1.05 ⎯ 1.05 ⎯
Instruction
Execution time in ON status (µs) Execution time in OFF status (µs)
Remarks
16-bit instruction 32-bit instruction 16-bit instruction 32-bit instruction
P*** 0.065 0.129 µs in P256 to P4095
I*** 0.065
Instruction
Standard mode Extension mode
Remarks
Execution time in ON
status (µs)
Execution time in OFF
status (µs)
Execution time in ON
status (µs)
Execution time in OFF
status (µs)
16-bit
instruc-
tion
32-bit
instruc-
tion
16-bit
instruc-
tion
32-bit
instruc-
tion
16-bit
instruc-
tion
32-bit
instruc-
tion
16-bit
instruc-
tion
32-bit
instruc-
tion
P*** 0.21 0.42
I*** 0.21 0.42
