FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
C Applied Instruction List [by Instruction Type/in Alphabetic Order]
C-1 Applied instructions [by instruction type]
C
Applicable Instruction List
D
Discontinued models
Appendix C: Applied Instruction List
[by Instruction Type/in Alphabetic Order]
Appendix C-1 Applied instructions [by instruction type]
Applied instructions are classified into the following nineteen types:
1 Data transfer instructions 11 Program flow control instructions
2 Data conversion instructions 12 I/O refresh instructions
3 Comparison instructions 13 Real time clock control instructions
4 Arithmetic operation instructions 14 Pulse output/positioning control instructions
5 Logical operation instructions 15 Serial communication instructions
6 Special function instructions 16 Special block/unit control instructions
7 Rotation instructions 17
Extension register/extension file register control
instructions
8 Shift instructions 18 FX
3U-CF-ADP instructions
9 Data operation instructions 19 Other handy instructions
10 Character string operation instructions
1. Data move instructions
Mnemonic FNC No. Function
Ref.
Page
MOV FNC 12 Move 243
SMOV FNC 13 Shift Move 246
CML FNC 14 Complement 248
BMOV FNC 15 Block Move 250
FMOV FNC 16 Fill Move 254
PRUN FNC 81 Parallel Run (Octal Mode) 451
XCH FNC 17 Exchange 256
SWAP FNC147 Byte Swap 535
EMOV FNC112 Floating Point Move 483
HCMOV FNC189 High-Speed Counter Move 590
2. Data conversion instructions
Mnemonic FNC No. Function
Ref.
Page
BCD FNC 18
Conversion to
Binary Coded Decimal
258
BIN FNC 19 Conversion to Binary 261
GRY FNC170
Decimal to
Gray Code Conversion
574
GBIN FNC171
Gray Code to
Decimal Conversion
575
FLT FNC 49
Conversion to
Floating Point
329
INT FNC129
Floating Point to
Integer Conversion
510
EBCD FNC118
Floating Point to Scientific
Notation Conversion
495
EBIN FNC119
Scientific Notation to
Floating Point Conversion
496
RAD FNC136
Floating Point Degrees to
Radians Conversion
521
DEG FNC137
Floating Point Radians to
Degrees Conversion
523
3. Comparison instructions
Mnemonic FNC No. Function
Ref.
Page
LD= FNC224
Load Compare
=
648
LD> FNC225
Load Compare
>
648
LD< FNC226
Load Compare
<
648
LD<> FNC228
Load Compare
≠
648
LD<= FNC229
Load Compare
≤
648
LD>= FNC230
Load Compare
≥
648
AND= FNC232
AND Compare
=
650
AND> FNC233
AND Compare
>
650
AND< FNC234
AND Compare
<
650
AND<> FNC236
AND Compare
≠
650
AND<= FNC237
AND Compare
≤
650
AND>= FNC238
AND Compare
≥
650
OR= FNC240
OR Compare
=
652
OR> FNC241
OR Compare
>
652
OR< FNC242
OR Compare
<
652
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
S 1 S 2
