Mitsubishi FX3U Series Programming Manual

926
FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
B Instruction Execution Time
B-6 Execution Time on Combination of Applicable Devices and Indexing
•FX3G/FX3GC PLCs
- Data comparison instruction (16-bit operation)
*1. When K4 is specified, and the head bit device number is a multiple of 8 (K4M0, K4M8 ...)
- Data comparison instruction (32-bit operation)
*1. When K8 is specified, and the head bit device number is a multiple of 8 (K8M0, K8M8 ...)
S (source)
D (destination)
Standard mode Extension mode
Without indexing (µs) With indexing (µs) Without indexing (µs) With indexing (µs)
KnY,
KnM,
KnS
T,C,D,R
KnY,
KnM,
KnS
T,C,D,R
KnY,
KnM,
KnS
T,C,D,R
KnY,
KnM,
KnS
T,C,D,R
KnX,KnY,KnM,KnS
*1
2.12 2.2 11.28 9.18 3 3.12 13.12 10.7
T,C,D,R 2.242.369.787.583.163.2411.529.32
K,H 1.4 1.52 8.88 6.78 2.12 2.24 10.32 8.12
S (source)
D (destination)
Standard mode Extension mode
Without indexing (µs) With indexing (µs) Without indexing (µs) With indexing (µs)
KnY,
KnM,
KnS
T,C,D,R
KnY,
KnM,
KnS
T,C,D,R
KnY,
KnM,
KnS
T,C,D,R
KnY,
KnM,
KnS
T,C,D,R
KnX,KnY,KnM,KnS
*1
2.52 2.76 11.68 9.68 3.48 3.68 13.32 11.32
T,C,D,R 2.8 3 10.72 8.28 3.72 3.92 11.92 9.92
K,H 1.4 1.76 9.28 7.28 2.36 2.68 11.12 9.12
