23 Introduction of Alternate Instructions – FNC180
23.1 Instruction correspondence table
21
FNC160-FNC169 Real Time Clock Control
22
FNC170-FNC179 External Device
23
FNC180 Alternate Instructions
24
FNC181-FNC189 Others
25
FNC190-FNC199 Block Data Operation
26
FNC200-FNC209 Character String Control
27
FNC210-FNC219 Data Operation 3
28
FNC220-FNC249 Data Comparison
29
FNC250-FNC269 Data Table Operation
30
FNC270-FNC275 Ex-Device Inverter Comms
23. Introduction of Alternate Instructions – FNC180
23.1 Instruction correspondence table
Outline
EXTR instruction is provided for FX2N and FX2NC PLCs.
For FX3G/FX3U/FX3GC/FX3UC PLCs equipped with the built-in inverter communication function, dedicated instructions
shown below are provided. (EXTR instruction is not provided.)
Instruction correspondence table
*1. This function is supported only in FX3U/FX3UC PLCs.
→ For details, refer to the Data Communication Edition manual.
FX2N/FX2NC FX3G/FX3U/FX3GC/FX3UC Description
EXTR K10 → FNC270 IVCK Inverter status check
EXTR K11 → FNC271 IVDR Inverter drive
EXTR K12 → FNC272 IVRD Inverter parameter read
EXTR K13 → FNC273 IVWR Inverter parameter write
– – FNC274
IVBWR
*1
Inverter parameter block write
– – FNC275 IVMC Inverter multi command
