FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
2 Overview (Sequence Program)
2.7 Types and Setting of Parameters
1
Introduction
2
Overview
3
Instruction List
4
Devices in Detail
5
Specified the Device & Constant
6
Before Programming
7
Basic Instruction
8
FNC00-FNC09 Program Flow
9
FNC10-FNC19 Move & Compare
10
FNC20-FNC29 Arith. & Logic Operation
2.7.4 Compatible optional memory model
1. FX3G PLCs
2. FX3U/FX3UC PLC
*1. Can be used with FX3UC PLCs Ver. 2.20 or later.
*2. Ver. 3.00 or later is applicable.
Model name
Maximum number of
steps
Memory type
Allowable number of
times of writing
Remarks
FX3G-EEPROM-32L 32000
EEPROM
memory
10000 times
Write-protect switch and loader
function are provided.
Model name
Maximum number of
steps
Memory type
Allowable number of
times of writing
Remarks
FX3U-FLROM-64 64000 Flash memory 10000 times Write-protect switch is provided.
FX3U-FLROM-16
*1
16000 Flash memory 10000 times Write-protect switch is provided.
FX3U-FLROM-64L
*1
64000 Flash memory 10000 times
Write-protect switch and loader
function are provided.
FX3U-FLROM-1M
*2
64000 Flash memory 10000 times
Write-protect switch and there is an
area (1300 kB) dedicated to the
storage of symbolic information.
