Mitsubishi FX3U Series Programming Manual

921
FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
B Instruction Execution Time
B-4 Applied Instruction Execution Time
31
FNC276-FNC279 Data Transfer 3
32
FNC280-FNC289 High-Speed Processing 2
33
FNC290-FNC299 Extension File Register
34
FNC300-FNC305 FX
3U
-CF-ADP
35
SFC•STL Programming
36
Interrupt Function
37
Special Device
38
Error Code
A
Version Up Information
B
Execution Times
Data comparison
233 ADN> 1.88 2.24 1.84 2.28 2.6 3.2 2.6 3.2
For details, refer to
Appendix B-6-2.
234 AND< 1.92 2.36 1.84 2.18 2.68 3.28 2.56 3.16
For details, refer to
Appendix B-6-2.
236 AND<> 1.48 1.68 1.5 1.7 2.24 2.64 2.24 2.64
For details, refer to
Appendix B-6-2.
237 AND<= 1.8 2.2 1.88 2.26 2.56 3.16 2.68 3.24
For details, refer to
Appendix B-6-2.
238 AND>= 1.8 2.16 1.92 2.32 2.52 3.12 2.64 3.24
For details, refer to
Appendix B-6-2.
240 OR= 1.54 1.76 1.52 1.72 2.28 2.68 2.24 2.64
For details, refer to
Appendix B-6-2.
241 OR> 1.92 2.32 1.88 2.32 2.64 3.24 2.64 3.24
For details, refer to
Appendix B-6-2.
242 OR< 1.96 2.36 1.84 2.28 2.68 3.28 2.6 3.2
For details, refer to
Appendix B-6-2.
244 OR<> 1.52 1.72 1.56 1.76 2.24 2.64 2.28 2.68
For details, refer to
Appendix B-6-2.
245 OR<= 1.84 2.2 1.92 2.32 2.56 3.16 2.64 3.24
For details, refer to
Appendix B-6-2.
246 OR>= 1.84 2.2 1.96 2.36 2.56 3.16 2.68 3.28
For details, refer to
Appendix B-6-2.
External device communication (inverter communication)
270 IVCK 32.60 ⎯ 4.46 ⎯ 33.90 ⎯ 4.88 ⎯
271 IVDR 31.60 ⎯ 4.46 ⎯ 32.40 ⎯ 4.88 ⎯
272 IVRD 35.30 ⎯ 4.46 ⎯ 36.60 ⎯ 4.88 ⎯
273 IVWR 34.60 ⎯ 4.46 ⎯ 35.40 ⎯ 4.88 ⎯
275 IVMC 44.2 ⎯ 4.46 ⎯ 45.4 ⎯ 4.88 ⎯
Extension file register control
290 LOADR 107.23+30.25n ⎯ 0.61 ⎯ 108.59+30.33n ⎯ 0.8 ⎯
294 RWER 4692.4+128.57n ⎯ 0.61 ⎯ 4700.4+128.57n ⎯ 0.8 ⎯
n:Number of write points
(Unit: Word)
FNC
No.
Instruc-
tion
Standard mode Extension mode
Remarks
Execution time in ON status (µs)
Execution time
in OFF status
(µs)
Execution time in ON status (µs)
Execution time
in OFF status
(µs)
16-bit
instruction
32-bit
instruction
16-bit
instruc
tion
32-bit
instruc
tion
16-bit
instruction
32-bit
instruction
16-bit
instruc
tion
32-bit
instruc
tion

Mitsubishi FX3U Series Specifications

General

Model	FX3U Series
Program Memory	64k steps
Execution Speed	0.065 μs/basic instruction
Type	PLC (Programmable Logic Controller)
Power Supply	100-240V AC
I/O Points	Up to 384
Communication	USB
Expansion	Supported via expansion modules
High-Speed Counters	Up to 6 channels
Analog Input/Output	Available via expansion modules
Temperature Range	0 to 55°C
Programming Language	Ladder Logic, Structured Text
Built-in Functions	PID control
Humidity	5 to 95% (non-condensing)
