FX3G/FX3U/FX3GC/FX3UC Series

Programming Manual - Basic & Applied Instruction Edition

A Programming Tool Applicability and Version Upgrade History

A-1 Programming Tool Applicability

3) FX-30P

FX-30P is applicable to FX3G/FX3GC/FX3U/FX3UC PLCs starting with the following version:

a) FX3G PLC

b) FX3GC PLC

c) FX3U PLC

d) FX3UC PLC

FX3G PLC version Model name Applicable FX-30P version Remarks

Ver. 1.00 FX-30P Ver. 1.00 or later

FX-30P (from first version) supports

FX3G PLC (Ver. 1.10 or later).

The IVMC instruction is not supported.

FX3GC PLC

version

Model name Applicable FX-30P version Remarks

Ver. 1.40 FX-30P Ver. 1.30 or later The IVMC instruction is not supported.

FX3U PLC version Model name Applicable FX-30P version Remarks

Before Ver. 2.41

FX-30P

Ver. 1.00 or later

Ver. 2.70 Ver. 1.20 or later

FX3UC PLC

version

Model name Applicable FX-30P version Remarks

Before Ver. 2.41

FX-30P

Ver. 1.00 or later

Ver. 2.70 Ver. 1.20 or later
