FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
A Programming Tool Applicability and Version Upgrade History
A-3 Version Upgrade History
*1. The FX3UC-32MT-LT supports Ver. 2.41 from the manufacturer's serial number "7X****" (October 2007).
*2. Available in Ver. 2.70 or later of FX3UC-32MT-LT-2 PLC.
*3. This function is supported only in the FX3UC-32MT-LT(-2).
→ For the manufacturer’ serial number check method, refer to Appendix A-3-1.
Ver. 2.20
55****
(May, 2005)
Supports the functions described as "Ver. 2.20 or later" in this manual.
• Supports the following 28 instructions:
ZPUSH(FNC102), ZPOP(FNC103), WSUM(FNC140),WTOB(FNC141),
BTOW(FNC142),UNI(FNC143), DIS(FNC144), SORT2(FNC149), TBL(FNC152),
COMRD(FNC182), DUTY(FNC186), BK+(FNC192), BK-(FNC193),
BKCMP=(FNC194), BKCMP>(FNC195), BKCMP<(FNC196),
BKCMP<>(FNC197), BKCMP<=(FNC198), BKCMP>=(FNC199), STR(FNC200),
VAL(FNC201), INSTR(FNC208), FDEL(FNC210), FINS(FNC211),
DABIN(FNC260), BINDA(FNC261), RBFM(FNC278), WBFM(FNC279)
• Adds function of the following 5 instructions:
SPD(FNC 56), DSZR(FNC150), DVIT(FNC151), ZRN(FNC156), PLSV(FNC157),
HCMOV(FNC189)
• Supports connection of FREQROL-F700/A700 inverters supporting the following 5 instructions:
IVCK (FNC270), IVDR (FNC271), IVRD (FNC272), IVWR (FNC273), and IVBWR (FNC274)
• Adds second entry code
(when GX Developer SW8.23Z (Ver. 8.23Z or later) is used).
• Supports BFM initial value setting function
(when GX Developer SW8.23Z (Ver. 8.23Z or later) is used).
• Mitigates restriction in writing during RUN
(when GX Developer SW8.23Z (Ver. 8.23Z or later) is used).
- Number of steps which can be changed by one-time write during RUN is changed.
127 steps → 256 steps
- Handling of circuit blocks which can be changed by one-time write during RUN is changed.
Program of continuous circuit blocks having 127 steps or less →
Program of circuit blocks having 256 steps or less in total
Ver. 2.30
5Y****
(November, 2005)
Adding the following instructions and function upgrade.
Adding MEP and MEF instructions
Function upgrade of MUL (FNC 22), DIV (FNC 23), and RS2 (FNC 87) instructions.
Ver. 2.41
79****
*1
(September, 2007)
•FX3UC-MT/D(SS) (First product)
• The baud rate "38400 bps" is supported in the RS and RS2 instructions, inverter
communication and computer link.
Ver. 2.53
84****
(April, 2008)
FX3UC-32MT-LT-2 (First product)
Ver. 2.61
*2
97****
(July, 2009)
• Supports the following 6 instructions:
FLCRT (FNC300), FLDEL (FNC301), FLWR (FNC302), FLRD (FNC303),
FLCMD (FNC304), FLSTRD (FNC305)
• Supports connection of the following special adapters:
-FX3U-3A-ADP
-FX3U-CF-ADP
• Supports the hardware error function of FX3U-4DA-ADP.
• Customer keyword / permanent PLC lock is supported.
Ver. 2.70
107****
(July, 2010)
•FX3UC-16MR/D-T, FX3UC-16MR/DS-T (First product)
• Supports the following 3 instructions:
VRRD(FNC85), VRSC(FNC86), IVMC(FNC275)
• Supports connection of the following analog volume expansion board:
-FX3U-8AV-BD
*3
• Supports the lower over-scale detection function of FX3U-4AD-ADP and FX3U-3A-ADP.
Ver. 3.00
115****
(May, 2011)
• Supports storage of symbolic information.
• Support of the setting "Read-protect the execution program" for block passwords.
• Special block error condition (D8166) is added.
• Supports connection of following memory cassette.
-FX3U-FLROM-1M
Ver. 3.10
11Y****
(November, 2011)
• Supports the following functions of the FX3U-16CCL-M:
- Network parameter
- Accessing the other station from CC-Link
- Remote device station initialization procedure registration
- CC-Link diagnostics
• Special parameter error (M8489 and D8489) is added.
Version
Manufacturer’s
serial number
Contents of version upgrade
To Next Page
