PROFIBUS/DP
The open PROFIBUS/DP network enables extremely fast data exchange with a very wide vari
-
ety of slave devices, including:
쎲
Remote digital I/Os and remote analog I/Os
쎲 Frequency inverters
쎲 Operator terminals
쎲 A range of other devices from third-party manufacturers
To help reduce costs PROFIBUS/DP uses RS 485 technology with shielded 2-wire cabling.
CC-Link
The open fieldbus and control network CC-Link provides a fast data communications with dif-
ferent devices. The following components from MITSUBISHI ELECTRIC among others can be
integrated:
쎲 MELSEC PLC systems
쎲 Remote digital I/Os and remote analog I/Os
쎲 Positioning modules
쎲 Frequency inverters
쎲 Operator terminals
쎲 Robots
쎲 Third-party devices like bar code readers
Various data like digital and analog data can be exchanged easily. In addition to the cyclic
transmission of word data, CC-Link systems handle transient transmission (message trans-
mission) as well. This enables data communications with intelligent devices such as display
devices, bar code readers, measuring devices, personal computers and PLC systems (up to 24
CPUs) as well beside the analog and digital devices.
DeviceNet
DeviceNet represents a cost-effective solution for the network integration of low-level terminal
equipment. Up to 64 devices including a master can be integrated in one network.
AS Interface
The AS interface is an international standard for the lowest field bus level. The network suits
versatile demands, is very flexible and particularly easy to install. Suitable for controlling
Actuators, like solenoids or indicators and sensors, hence the name AS-i.
CANopen
CANopen is an “open” implementation of the Controller Area Network (CAN),
CANopen networks are used for connecting sensors, actuators and controllers in industrial
control systems, medical equipment, maritime electronics, railways, trams and commercial
vehicles.
CANopen Network modules are available for the MELSEC FX family of controllers.
MELSEC System Q Beginners Manual 3 – 39
Networks and Network Modules Das MELSEC System Q
