M Series AC Servo
User Manual
13
Rev. 1.0
7/31/2019
400-820-9661
2.2.4 Drive Dimensions (Unit: mm)
2.2.4.1 50W 100W 200W Type
150
41
150
145
2.2.4.2 400W Type
150
55
150
145
2.2.4.3 750W Type
150
65
176
150
