7.2.2.1 Input Pulse Type Setting
Parameter Pulse
CW direction
setting
CW CCW
setting value
(decimal)
P-42 (SZ)
Lower 8 bits
Step & Direction
X2 on
ON
OFF
Pules
ON
OFF
DIR
ON
OFF
Pules
ON
OFF
DIR
0
X2 O󰀨
ON
OFF
Pules
ON
OFF
DIR
ON
OFF
Pules
ON
OFF
DIR
4
CW/CCW
Pulse On X1
ON
OFF
CW Pulse
ON
OFF
CCW Pulse
ON
OFF
CW Pulse
ON
OFF
CCW Pulse
1
Pulse On X2
ON
OFF
CW Pulse
ON
OFF
CCW Pulse
ON
OFF
CW Pulse
ON
OFF
CCW Pulse
5
A/B Quadrature
X1 Lead X2
ON
OFF
A
ON
OFF
B
90°
ON
OFF
A
ON
OFF
B
90°
2
X2 Lead X1
ON
OFF
A
ON
OFF
B
90°
ON
OFF
A
ON
OFF
B
90°
6
7.2.2.2 Input Noise Filter Setting
The input noise lter is a low pass lter. When pulse input and output duty cycle is set to 50%, the P-43
(SZ) setting value are as follows
Parameter
setting value
(decimal)
Filter Frequency
setting value
(decimal)
Filter Frequency
P-42 (SZ)
Higher 8 bits
25344 100K 4864 500K
16640 150K 3072 750K
12544 200K 2304 1M
9984 250K 1792 1.2M
8192 300K 1280 1.5M
6144 400K 1024 2M
