M Series AC Servo
User Manual
8
Rev. 1.0
7/31/2019
400-820-9661
1 Introduction
1.1 About This Manual
This manual describes the M2 Servo Drive.
It provides the information required for installation, conguration and basic operation of the M2 series AC
servo drive.
This document is intended for persons who are qualied to transport, assemble, commission, and
maintain the equipment described herein.
1.2 Documentation Set for M2 series AC servo
This manual is part of a documentation set. The entire set consists of the following:
• M2 Quick Start Guide. Basic setup and operation of the drive.
• M2 User Manual. Hardware installation, conguration and operation.
• M Servo Suite Software User Manual. How to use the M Servo Suite software.
1.3 Safety
Only qualified persons may perform the installation procedures. The following explanations are for things
that must be observed in order to prevent harm to people and damage to property.
The M2 utilizes hazardous voltages. Be sure the drive is properly grounded.
Before you install the M2, review the safety instructions in this manual.
Failure to follow the safety instructions may result in personal injury or equipment damage.
1.4 Safety Symbols
Safety symbols indicate a potential for personal injury or equipment damage if the recommended
precautions and safe operating practices are not followed.
The following safety-alert symbols are used on the drive and in the documentation:
Caution Warning. Dangerous voltage. Protective earth Caution, Hot surface
