Moons' M2DV-1D82D User Manual

M Series AC Servo
User Manual
20
Rev. 1.0
7/31/2019
400-820-9661
□
80mm Dimension
1) Motor Dimensions – No Brake: mm 2) Motor Dimensions – Brake: mm
□
80mm Torque Curve
Max. Intermient Torque
Max. Connuous Torque
0
1
2
3
4
5
6
7
8
0 2,000 4,000 6,000
Torque (Nm)
Speed (rpm)
SM0803 (750 Watts) - Winding A
320 VDC (230VAC) - 4.5 Amps
3 ±0.2
9.5
L1 ±1
70 h7
- 0.03
0
19 h6
- 0.013
0
40 ±1
94
300
±50
300
±50
300
±50
Oil seal
0.04 A
0.04 A
A
4-
6.5
80
M5
10
6
h9
-
0.03
0
-KEY
21.5
- 0.118
+ 0.300
45°
90
3 ±0.2
9.5
L1 ±1
70 h7
- 0.03
0
300
±50
19 h6
- 0.013
0
40 ±1
94
Oil seal
0.04 A
0.04 A
A
4-
6.5
80
M5
10
6
h9
-
0.03
0
-KEY
21.5
- 0.118
+ 0.300
45°
90
300
±50
With Brake L1
SM0803AE
*
-KCD-BNV
178
Without Brake L1
SM0803AE
*
-KCD-NNV
131
