Radio Types and Installation Kits
21-63
External Modem Port Configurations
Configuration 1
External Modem
Line2
External Modem
Line2
External Modem/
Line2
LAN
SCADA
IP Gateway
RS232
iNET
Access
Point
Com2/
UDP
iNET UDP multicast
224.254.1.1/30011
Line 2
RTU 1
RS232
iNET
Remote
Com2/
UDP
RTU 2
RS232
iNET
Remote
Com2/
UDP
RS232
STS
Configuration 2
LAN
SCADA
IP Gateway
IP Cloud
iNET
Access
Point
Com2/
UDP
RS232
RTU 1
RS232
iNET
Remote
Com2/
UDP
RTU 2
RS232
iNET
Remote
Com2/
UDP
iNET UDP multicast #1
224.254.1.1
/30011
Line 2
LAN
Terminal Server
169.253.1.10
iNET
Access
Point
Com2/
UDP
RS232
External
Modem/
Line3
RTU 3
RS232
iNET
Remote
Com2/
UDP
RTU 4
RS232
iNET
Remote
Com2/
UDP
iNET UDP multicast #2
224.253.1.1
/30011
Line 3
External
Modem/
Line3
External
Modem/
Line2
External
Modem/
Line2
Link ID
Terminal Server Ports
169.254.1.10
Line 2
3024
169.253.1.10
Line 3
3024
IP Address
Tcp port
Terminal Server
169.254.1.10
LAN
