6881096C74-B May 25, 2005
Theory of Operation: Controller Section 3-77
For a list of all available programming cables, refer to the table below.
NOTE: In remote-mount configurations, the control head 10-pin microphone port is disabled for any
kind of programming.
NOTE: FLASH IC replacement is not supported as a field repair option. If the FLASH IC is removed,
the radio cannot be reflashed by a customer or radio depot. This is because the FLASH IC
must be hard-boot loaded at the factory to allow the programming of a unique file.
Table 3-17. Programming Cables
Motorola
Part Number
Description Application
HKN6155 Programming Flash Cable Used with Tuner software, Customer Programming
Software (CPS), and FLASHport
RVN4185 Customer Programming Software and
Tuner Software
Programming and radio alignment software on CD
HKN6182 High Power GCAI Cable Adapter for
Keyloader
Used for keyloading XTL 5000 High Power
HKN6183 High Power GCAI to RS232
Programming Cable
Used for programming XTL 5000 High Power
HKN6184 High Power GCAI to USB Programming
Cable
Used for programming XTL 5000 High Power
HKN6122 4-wire data cable, J6 remote TIB Used for programming XTL 5000
HKN6160 Cable Kit 6’ Dash Mount Data (RS232) Used for programming XTL 5000 Mid Power
If you choose to reflash the radio (reflash the IC), DO NOT interrupt the
process; otherwise, you might corrupt the FLASH IC and need advanced
technical support to revive your radio.
!
C a u t i o n
