Motorola ASTRO Digital XTL 5000 Detailed Service Manual

Flex Cable Pin-Out Lists: List of Flex Cables 9-1
6881096C74-B May 25, 2005
Chapter 9 Flex Cable Pin-Out Lists
9.1 List of Flex Cables
This chapter lists the pin-out assignments for the following flex cables:
• Mid Power Dash (Table 9-1 on page 9-1)
• Mid Power Rear Accessory (Table 9-2 on page 9-1)
• Mid Power Remote (Table 9-3 on page 9-2)
• High Power Remote (Table 9-4 on page 9-3)
9.2 Flex Cables
Table 9-1. Mid Power Dash Flex Cable J103 to P0401 Pin-Out List
Signal
J103
26-Pin
(Female)
P0401
50-Pin
(Male)
GND 3, 6 <--> 1, 2, 49, 50
SW B+ 4 <--> 17
A+ 5 <--> 19, 21
VIP OUT 2_5v 7 <--> 14
VIP OUT 1_5v 8 <--> 13
"BOOT_TX / Keyfail 9 <--> 25
BUS - 10 <--> 32
IGN 11 <--> 20
VIP OUT 1_12v 18 <--> 11
VIP OUT 2_12v 19 <--> 12
"OPT_B+ BOOT_SEL VPP" 20 <--> 22
"BOOT_RX / KVL_ATT" 21 <--> 26
BUS + 22 <--> 31
RESET 23 <--> 34
BUSY 25 <--> 33
MIC HI 27 <--> 4
NC Remaining pins <--> Remaining pins
Table 9-2. Mid Power Rear Accessory Flex Cable J2 to P0402 Pin-Out List
Signal
J2
26-Pin
(Female)
P0402
32-Pin
(Female)
GND 1, 14 <--> 1, 2, 14, 31, 32
BUS+ 2 <--> 3
BUS- 3 <--> 5
TX_DCE 4 <--> 7
RX_DCE 5 <--> 9
USB - 6 <--> 13
USB + 7 <--> 11
RESET 8 <--> 4
BUSY 9 <--> 6
RTS_DCE 10 <--> 8
CTS_DCE 11 <--> 10
USB PWR 12 <--> 12
CHAN ACTIVITY 13 <--> 15
Emergency 15 <--> 28
PTT*= AUX PTT 16 <--> 24
ONE WIRE 17 <--> 27
VIP OUT 1 18 <--> 16
VIP OUT 2 19 <--> 17
Spkr + 20 <--> 19, 21
RX_filt_audio 21 <--> 30
MONITOR / HUB 22 <--> 26
Aux_Mic 23 <--> 29
SW B+ 24 <--> 20, 22
IGN 25 <--> 18
Spkr - 26 <--> 23, 25
