Motorola ASTRO Digital XTL 5000 Detailed Service Manual

6881096C74-B May 25, 2005
Product Overview: Control-Head Assembly 2-3
Figure 2-2. VIP Remote-Mount Configuration
Figure 2-3. VIP Remote-Mount Pin-Outs (Male)
Control
Head
Main Board
(Radio)
U1
MC68HC
MAEPF-27922-O
MicroprocessorSIOIC
SB9600 data
lines toggle
VIP-OUT
hadware
inside the
Control Head
VIP OUT 1
VIP OUT 2
1 2 3 4 5 7 8 10 11 12 13 14 15 16 17
18 19 20 21 23 24 26 27 28 29 30 31 32 33
34 35 36 37 38 40 41 43 44 45 46 47 48 49 50
SWB SWB GND GND
MICVIP RADIO
11
VIP OUT VIP IN
22
VIP OUT VIP IN
+
SWB GND
+
+
MAEPF-27918-O
