Motorola ASTRO Digital XTL 5000 Detailed Service Manual

Flex Cable Pin-Out Lists: Flex Cables 9-3
6881096C74-B May 25, 2005
Table 9-4. High Power Remote Flex Cable P0401 to J512 Pin-Out List
Signal
P0401
60-Pin
(Male)
J512
80-Pin
(Female)
GND 1,2,23,52,59,60 <--> 1,2,9,38,69,70,79,80
PTT 58 <--> 3
MIC_HI 57 <--> 4
RX_FILT_AUDIO 56 <--> 5
AUX_MIC 55 <--> 6
AUX_TX 54 <--> 7
AUX_RX 53 <--> 8
EMERGENCY 51 <--> 10
VIP IN 1 (5V) / NAUT
STATUS
50 <--> 11
VIP IN 2 (5V) / NAUT CONF
DONE
49 <--> 12
VIP OUT 1 (5V) / NAUT
CONFIG
48 <--> 13
VIP OUT 2 (5V) / NAUT
RESET
47 <--> 14
VIP OUT 1 (12V) 46 <--> 15
VIP OUT 2 (12V) 45 <--> 16
KEYFAIL 44 <--> 17
BUS_PWR_OUT 43 <--> 18
ONE-WIRE 42 <--> 19
GPIO0 41 <--> 20
SPARE GPIO 40 <--> 21
GCAI_USB-RS232 39 <--> 22
SPK+ 37, 38 <--> 23, 24
SPK- 35, 36 <--> 25, 26
SW_B+ 33, 34 <--> 27, 28
A+ 29, 30, 31, 32 <--> 29, 30, 31, 32
IGNITION 27, 28 <--> 33, 34
OPTB+ 26 <--> 35
SW_5V 25 <--> 36
VBUS_PWR_IN 24 <--> 37
BOOT TX-USB+ 22 <--> 39
BOOT RX-USB- 21 <--> 40
TX_DCE 20 <--> 41
RX_DCE 19 <--> 42
RTS_DCE 18 <--> 43
CTS_DCE 17 <--> 44
BUS+ 16 <--> 45
BUS- 15 <--> 46
LH_BUSY 14 <--> 47
LH_RESET 13 <--> 48
SAP-TX (SRDA) PATRIOT 12 <--> 57
SAP-RX (STDA) PATRIOT 11 <--> 58
SAP-DCLK 10 <--> 59
SAP-FSYNC 9 <--> 60
NAUTILUS-CS 8 <--> 61
NAUTILUS-INT 7 <--> 62
SPI-MOSI 6 <--> 63
SPI-MISO 5 <--> 64
SPI-CLK 4 <--> 65
SSI_INT 3 <--> 66
NC Remaining Pins <--> Remaining Pins
Table 9-4. High Power Remote Flex Cable P0401 to J512 Pin-Out List (Continued)
Signal
P0401
60-Pin
(Male)
J512
80-Pin
(Female)
